MAT 1340

  • Reference ID 543
  • Builder MAT Yachts(New builds)
  • Model Mat 1340
  • Mills Yacht Design
  • Year 2020
  • Location Turkey
  • L.O.A. (mtr) 13.40
  • Beam (mtr) 4.24
  • Draft (mtr) 2.65
  • Displacement (Kg) 7150
  • Material Composite
  • Engine Yanmar
  • Berths 8

Yacht description

M.A.T. 1340
13.40 m IRC Racer / Cruiser



This 44’ IRC special is the result of an extensive R&D phase aimed at optimising under IRC both inshore and offshore and ended up with a solution significantly faster on corrected time than an aggressive ‘Mini-TP’ model. These features of medium/light displacement, fin keel, moderate sail area, and the option of twin rudders enable reduced crew numbers especially offshore.

Mat Yachts: 'This is the fourth project with Mills design over 14 very productive years working together. Since the cooperation we have become successful worldwide with focus on high performance, cost-effective boat building, ensuring this new design has the best opportunity to succeed both inshore and offshore.'

Sail world writes:

'So whilst the rules will continue not to favour the lightweight whiz-bang, it is important to remember that with the MAT 1340 you’ll have better behaviour and a kinder motion. It will be nicer to race, you have three full cabins and all the amenity that brings, a huge cockpit (especially without a pedestal), and it will still get up and be on the plane in a solid squirt. i.e. No ocean grading going on here.'


She features:

  • milled keel
  • carbon stick
  • rod rigging
  • rigid vang
  • Harken deck gear



GENERAL INFO:

Hull Length: 13.40
Beam max: 4.24
Draft: 2.65 m
Displacement: 7.150 kg

Construction
ISO 12215 structural regulations category A
Hull, deck, bulkheads, interior components in PVC foam cored composite glass/carbon sandwich
Vacuum assisted resin infusion

Rigging

Axxon Composites

  • HR standard modulus carbon fiber mast
  • Section 150x258
  • 2:1 main halyard sheave box
  • Double masthead sheave box for spi/code 0
  • 2 x mast head backstay to winches
  • Single sheave box @headstay height jib/genoa/solent
  • 2 sets of aluminum spreaders
  • Structural staysail sheave box
  • Carbon gooseneck and vang bracket
  • Rigid vang
  • HR standard modulus carbon max depth boom
  • RAL 9005 black or RAL 9016 white finish
  • BSI Rod rigging
  • Prepreg carbon autoclave cured bow sprit

Accommodations

  • Bulkheads and interior components in PVC foam cored composite glass/carbon sandwich
  • Honeycomb cored sandwich natural oak veneer cabin doors and cabinet doors
  • Lightweight composite nonskid floor boards
  • Custom alloy door frames, custom alloy cabinets, alloy handrails
  • Southco Marine door and cabinet handles High density foam cushions, Sunbrella upholstery
  • Lightweight composite companionway ladder for easy access to engine
  • 3 cabins
  • Head with shower and toilet
  • Sleeps 8

Galley

  • Dometic gimballing two burner gas cooker
  • GRP refrigerator compartment, Vitrifigo 12V cooling compressor

Plumbing

  • Plastimo 200 l flexible fresh water tank
  • Jabsco pressurized water system
  • Can Marine hand basin in head, Whale mixer tap
  • Can Marine twin galley sink, Whale mixer tap
  • Jabsco manual bilge pump 3000 l/h cockpit
  • Jabsco manual bilge pump 3000 l/h cabin
  • Rule electric bilge pump 7570 l/h
  • Jabsco marine manual toilet
  • Southco fresh water fill on deck
  • Forespar racing marelon flush valves

Deck and Cockpit

  • 7 x Harken Performa 50.2 STP racing winches
  • Harken mainsheet track and 2:1 mainsheet to winch
  • Harken transverse jib tracks and cars
  • Harken Black Magic halyard lead blocks
  • Harken Black Magic sheet and other primary blocks
  • Harken Carbo control blocks
  • Spinlock XXA and XCS clutches
  • Custom alloy fairleads
  • 5 mm SS lifelines, Blue Wave terminals
  • 4 opening Lewmar portlights
  • 3 opening Lewmar hatches
  • Custom tempered glass coachroof windows
  • Custom stainless steel chainplates recessed in hull
  • Composite mast collar
  • Recessed companionway sliding hatch
  • Locker for gas bottle

Electrics

  • 12V circuit
  • Victron Energy 2 x 140 A AGM deep cycle house batteries
  • Victron Energy 1 x 80 A starter battery
  • BEP Marine battery switches
  • BEP Marine distribution switch panel
  • Victron Energy battery management system
  • Frensch GmbH LED interior lights
  • Lopolight LED navigation lights
  • ISO wiring
